System requirements for h/p/cosmos para control 4.2
- Personal Computer or laptop / notebook with Pentium IV Processor or higher
- min. installed operating system Windows 7
- min. 1 GB RAM (2 GB RAM recommended)
- min. 200 MB free memory on HD
- VGA-Monitor min. 1280 x 1024
- Microsoft .NET Framework 3.5 Service Pack 1
- Microsoft® DirectX 9.c
- free RS 232 interface port for connection of any peripheral equipment.
- RS232 COM port is strongly recommended on the PC/Laptop
- (USB port and converter not preferred, but possible)
- for control via USB interface an optional converter (not all converters work!) is available at h/p/cosmos
- for control via USB interface the processor must be Pentium 2.0 GHz or higher
- Running-machine with RS 232 interface and selected coscom v3 protocol.
- If the UserTerminal is MCU2 or MCU3 type, then the EPROM firmware release must be at least V 2.31.
